SCM3000/SCM1400L
ARGUS
Top 1 Denim jeans laser printing,engraving,washing,whisker machine.
The SCM1400L 3D Dynamic CO2 Laser Marking Machine is specialized designed for denim Laser Marking Application, which is widely used in the jeans producing, and it is also the most popular model in the market.It is the outcomes of SUNIC Laser’s technical expertise and experience in marking and engraving denim for jeans applications exploiting proprietary laser technology to produce washing mark, whisker result on denim up to four switch table 1300×600 mm working size. This process is much more productive in comparison to other traditional technologies and other lasers, even with the maximum quality.
CO2 Dynamic Laser Marking Machine SCM3000 main structures:
Imported laser tube
High speed galvo scanner
Sunic Laser self-developed linear 3D Dynamic Focusing System
Device control system
Self-developed Control software
The high precision thermostatic water cooling system.
The host machine is as follow:
Machine’s Control section is focused on the Electrical main control section. The whole machine’s optical components are focused on the optical main beam and inside the square head through the complete optical design. The integrated water chiller provides a circulation water cooling system for the machine during working. CO2 Dynamic Laser Marking Machine mainly includes the following parts:
Optical System
Water Cooling System
Electrical Control System
IPC&Marking Motion Card
Sunic Laser Self-developed Control Software
Exhausting System
Model | SCM3000 | SCM1400L |
Max working Area | 1500*1500mm | switch table:1300*400mm *4 |
Laser power | 250 watts/350watts | 250 watts/350watts/500watts |
Power Consumption | ≤ 7kWh | ≤ 7kWh |
Life Span | Over 20000 hours | Over 20000 hours |
Marking Speed | ≤10000mm/s | ≤10000mm/s |
Worktable | Marble worktable | MDF/Strip/Honeycomb worktable |
Laser Source | US Coherent Diamond J Series Laser Tube | US Coherent Diamond J Series Laser Tube |
Laser Wavelength | 10.64μm | 10.64μm |
Laser Frequency | 20kHz~200kHz | 20kHz~200kHz |
Focusing method | 3D dynamic focusing system | 3D dynamic focusing system |
System Support | Windows | Windows |
Output Compatibility | Auto CAD, Photoshop, CorelDRAW etc | Auto CAD, Photoshop, CorelDRAW etc |
File Formats | PLT, DXP, BMP, JPG, AI etc | PLT, DXP, BMP, JPG, AI etc |
Software Character | Integrated Function of Dotting Design, Vector Drawing, Marking, Scribing and Cutting | Integrated Function of Dotting Design, Vector Drawing, Marking, Scribing and Cutting |
Power Supply | 110V~380V/50Hz~60Hz | 110V~380V/50Hz~60Hz |
Cooling Way | Circulation of Water Cooling | Circulation of Water Cooling |
The denim processed by Laser Engraving display the excellent features of quick producing speed, no need washing process, Environment friendly, easy customized design, and permanent result.Technical Parameters
Packaging
Size：1000(L)*800(W)*600(D)
Gross Weight：400KG
Packaging Details：Standard Crate for export. Whole machine will be covered with film before packing.
