| Quantity: | |
|---|---|
3015D-W
ARU
Product Paramenters
Laser 3015 Cutting Machine Parmeters | |
Laser Power | 1500W/3000W/6000W |
Wavelength | 1080±3nm |
Laser method | Fiber Laser |
Power adjustable range | 10-100% |
Laser Source Brand | MAX/RAYCUS/RECI |
Cutting speed | 0-100m/min |
Workable field | 3000*1500mm |
Size | 4430*2270*1850mm |
Weight | 3800kg |
Machine power consumption | ≤12KW |
Working voltage | 380V /50-60Hz /4.5Kw (Customized) |
Cooling system | Water cooling |
Working temperature | 10-40℃ |
Storage temperature | -20-50℃ |
Humidity | 0-90℃ |
Products Handled | Sheet Metal construction |
Graphic Format Supported | AI, PLT, DXF, BMP, DST, DWG, LAS, DXP |
Technical Parameter
Laser source
Better beam quality and powerful anti-reaction ability ensure stable and precise cutting in thick plates. The narrow slit and
bright section of the cut plate offer clear advantages over similar lasers on the market.
Plate Welding Heavy Work Bed
Annealed and heat-treated plate welding ensures a heavy-duty work bed with no deformation for 20 years, suitable for ultra-high power 10,000-watt lasers. The increased weight significantly enhances the cutting speed of the laser cutting machine.
Servo Motors and Drivers
Famous brand servo provides balanced and stable driving force, low noise, and smooth movement. Synchronization is error-free, with
higher positioning accuracy and faster positioning speed.
Gear rack
High stability and precision with long-term resistance to deformation. The X/Y axis uses a high-precision rack and pinion with a
low-backlash reducer for lasting motion accuracy. The Z-axis features a precision ball screw drive and linear guide rail for
stable operation and fast response.
Independent electrical cabinet
This mobile electrical cabinet, featuring Air switch plugs, streamlines installation by reducing the need for extensive wiring,
saving time during setup and equipment maintenance. It segregates power systems, minimizing failure rates, and includes a
comprehensive safety circuit distribution system.
Automatic cleaning and calibration system for nozzles
Automated nozzle cleaning and calibration lessen reliance on operator skill, enhancing equipment efficiency and maintenance. This
boosts equipment intelligence and improves user experience
Auxiliary feeding safety protection fence
Three-sided feeding auxiliary device: Equipment can be loaded from three directions, facilitating customers in arranging equipment
layout effectively.
Products Description
What is fiber laser cutting machine application ?
Fiber laser cutting machine is a new technology special for cutting most of metal , Material Application:Stainless steel, carbon steel, alloy steel, silicon steel, aluminum,aluminum alloy, galvanized sheet, pickled sheet, copper, silver, gold, titanium and other metal sheet marking and engraving. Compare with traditional cutting , it has many advantage as follow:
1.Easy to operate , no need any experience, even a women also can did well on it .
2. High efficiency , 2-4 times faster than traditional cutting.
3. Cost is much lower, labor cost and electricity cost are reduced by at least 50%.
4. Employee safety. No radiation, no harm to people, just wear glasses.
Samples
Customer Photos
Recommend Products
Recommended by seller
sunic precision tube cnc metal fiber laser pipe cutting machine price china industrial high accuracy 5 axis 3000w cutter
$30,600.00 - $34,000.00 / set
1 set
ARGUS CO2 Laser Engraving and Cutting Machine Factory Cost 130W Laser Cutter for Metal and Wood Acrylic
$3,000.00 - $4,000.00 / set
1 set
ARGUS 1000w 2000w 3000W Fiber Laser Cutting Machine For Stainless steel Aluminum Carbon Steel sheet and tube
$25,000.00 - $29,000.00 / set
1 set
Big Power 1000W/1500W/2000W Metal CNC Fiber Laser Cutting Machine
$24,000.00 / set
1 set
Company Profile
ABOUT SUNIC GROUP
Wuhan Sunic Group is a professional laser machines and solar panel products lines equipments manufacturer since 1998. We are specialized in Design, R&D, Manufacture, Sales and Service for laser machines.
We supply customized solution for different materials processing , such as Invitation cards, Wedding cards, Pop up cards, Pop up books , Candy box , Paper products, Acrylic , PMMA, LGP, Jeans Wash, Leather, Fabric, Textiles, Wood, MDF, Laminate materials ,Marble, Package Film, Metal / Plastic products, etc.
Our laser equipment is widely used in Solar Photovoltaic production line, IC Component Production, Leather&Garment Industry, Advertising Signs, Decoration crafts, Equipment spare parts, Daily hardware, Measurement tools, Medical instruments, Printing&packing industries, etc. Sunic Group would like to be customer's technical laser and solar equipment consultation and support for further development and progress together.
FAQ
What kind of laser machine and model should I choose?
You can tell us your processing material, working size and detail requirement, detail work by picture or video so that we can judge whether our machine can meet your need
What kind of materials does the laser machine can process?
We have different laser machines, such as Fiber laser, CO2 Laser, UV Laser Green Laser. Normally Fiber laser can process metal and plastic. CO2 laser is for processing non metallic materials, such as Acrylic, PMMA,Wood, Glass, Leather,Jeans, Paper, Textiles Garments and so on. UV laser and green laser are also called cold laser source, they are usually used for plastic, glass, crystal and some special processing job.
Is it easy to operate?
We will send you manual and guide video in English, I can teach you how to operate the machine. lf you still can not learn how to use it, we can help you by Team viewer online help software.Or we can talk by phone email or other contact ways.
What s your guarantee. in case the machine breaks down?
The machine has one year guarantee. If it breaks down, generally speaking our technician will figure out what the problem may be, according to client's feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.
How will you do the after- sale service?
We will firstly check your problems online through Team viewer,E-mail, Whatsapp or other contact way, if it is easy to handle it, we will guide you online to fix it or send you the spare parts for replacement.
What is your equipment lead time?
Fiber laser marking machine lead time is around 7 working days. CO2 laser engraving&cutting machine lead time is around 2-3 weeks 3D dynamic CO2 laser marking machine lead time is around 10 working days.
How will you do the package and shipping?
All of our equipment are packed in export standard cases. Express, air shipping, sea shipping are all available.
