SCU5070
ARGUS
6 ADVANTAGE
| Long lifespan low maintenance cost |  |
Max Engraving Speed：2000mm/s | |
High Repeat Precision：0.15mm | |
Electric lift worktable easy for processing diverse thickness sheets | |
All electrical parts strictly conform to CE Standard | |
Glass Tube life can reach 10000 Hours RF metal laser tube available |
| Model | SCU5070H |
| Working Platform Size | 500*600mm |
| Laser Power | 30W/60W |
| Max Engraving Speed | 2,000mm/s |
| Max. Cuttin Speed | 400mm/s(depends on material) |
| Repeated Positioning Accuracy | ±0.15mm |
| Min Cutting Character | English Letter：1.5mm |
| Max. Cutting Depth | 6 ~ 8mm(up to the material) |
| Table Height Adjustment | 25cm Adjustable |
| Red Pointer | 650nm |
Controlling system | RDCAM |
| Table Type | Honeycomb or blade |
Mo Mirror Reflectivity | 95% |
| Focus Lens | 2.0 inch |
| Mix Cutting Character | English Letter：3mm |
| DC brushless servo motor | Brand: Leadshine, rated speed：3,000rpm |
| Cooling Ways | Circulation Water Cooling |
| Air Pump | Power：138W |
| Flow Rate：100L/Min | |
| Voltage：220V | |
| Exhaust Fan | Power:550W |
| Blowing Rate：18m³/min | |
| outlet diameter：80mm | |
| Wind Pressure：1.70Kpa | |
| Rotaing Speed：2800RPM | |
| Software Format Support | CorelDraw, Photoshop,AutoCAD,etc |
| Graphic Format Support | AI, PLT,BMP, DXF,DST,T100,etc |
| Working Temperature | 0-35°C |
| Working Humidity | 5-95% |
| Working Power | 220V/50Hz/60Hz/2kVA,110V/50Hz/60Hz/2kVA (can customize） |
Packing Dimension | 1750*1100*1250mm |
Our CO2 laser engraving cutting machines offer a solution for highquality engraving and cutting of acrylics, cardboard, wood,textiles,two-color sign laminate, stone, and much more. Our laser machines are the most robust,accurate, and reliable on the market.
 | Choice of Support Tables
We provide both a blade & Honeycomb table for laser engraving and cutting |
Control Software
Friendly software, enabling the import of files: plt, ai, bmp, dxf, dst, having many useful functions, defining work values assigned to a given line color (cutting, engraving, laser speed and power) |  |
 | Pass-through Door
Pass-through front to rear doors |
Visible Red Dot Pointer
Since the CO2 laser beam is invisible the red dot pointer on the machine allows you to have a visual reference for locating where the laser will fire. |  |
 | High Performance Motors
Stepper motor is in high precision, high speed, large torque, performance is stable and durable, ensure the high speed operation of the whole machine. |
| Unique Module Structure
The unique module structure is formed in one time assembly to avoid to manually assemble,more accuracy;Keep A axis and Y axis both 90°for 7-10 years. |  |
 | Linear Guide Rail
Adopted Taiwan Hiwin linear guide rail,high positioning accuracy, reduce wear to maintain accuracy for a longer time. |
Yongli Glass Tube
High quality laser beam,Easy to change and Long life span 12,000hrs. |  |
With better hardware stbilty better resance to high voltage, anti-static interference.The 3.5-inch color screen man-machine operating system has amore friendly interface and powerful functions. The cotoller includes the best motion control features,a larger capacity file memory, a more compatible dual independent adjustable laser power control interface and a USB flash drive, and multiplexed/dedicated 10 control.PC communication supports Ethermet communication and USB communication. Equipped with awireless WIFI converer, itcan esabisha WIF-based wreles controlLAN with the laser machine, getrid of the wired network cnnecon, reduce user cost and inrease feibiy.
| MATERIAL | CUT | ENGRAVE |
| Paper | ✔ | ✔ |
| Cloth | ✔ | ✔ |
| Wood | ✔ | ✔ |
| MDF | ✔ | ✔ |
| Wood Veneer | ✔ | ✔ |
| Acrylic | ✔ | ✔ |
| Leather | ✔ | ✔ |
| Press Board | ✔ | ✔ |
| Cork | ✔ | ✔ |
| Rubber | ✔ | ✔ |
| Bamboo | ✔ | ✔ |
| Double color | ✔ | ✔ |
| Plastic | ✔ | ✔ |
| Glass | X | ✔ |
| Ceramic | X | ✔ |
| Tile | X | ✔ |
| Marble | X | ✔ |
| Plyeood | ✔ | ✔ |
| ACRYLIC | |||
 |  |  |  |
| RUBBER | |||
 |  |  |  |
| WOOD | |||
 |  |  |  |
| MARBLE | |||
 |  |  |  |
| PAPER | |||
 |  |  |  |
