SFC3015
Argus
1.In order to meet the increasingly complex needs of consumers, Argus is targeted at market demand, independently developed SFC3015 metal sheet laser fiber cutting machine with stable and high precision cutting performance.
2. Low cost and the power consumption ; Customer can cut all kinds of metal sheets by blowing air.
3. High-performance. Use top brand fiber laser source, with stable performance and the lifespan is over 100,000 hours.
4. High speed and efficiency, the speed of cutting metal sheets close to tens of meters.
5. The laser maintenance free.
6. The cutting edge looks perfect and the appearance is smooth and beautiful.
7. Imported the transmission mechanism and servo motor, and high cutting accuracy.
8. Dedicated software enables graphic or text to be instantly designed or processed. Flexible and easy operation.
1.In order to meet the increasingly complex needs of consumers, Argus is targeted at market demand, independently developed SFC3015 metal sheet laser fiber cutting machine with stable and high precision cutting performance.
2. Low cost and the power consumption ; Customer can cut all kinds of metal sheets by blowing air.
3. High-performance. Use top brand fiber laser source, with stable performance and the lifespan is over 100,000 hours.
4. High speed and efficiency, the speed of cutting metal sheets close to tens of meters.
5. The laser maintenance free.
6. The cutting edge looks perfect and the appearance is smooth and beautiful.
7. Imported the transmission mechanism and servo motor, and high cutting accuracy.
8. Dedicated software enables graphic or text to be instantly designed or processed. Flexible and easy operation.
Model | SFC3015 |
Laser type | Fiber laser,1080nm |
Laser power | 1000W,1500W,2000W,3000W,4000W,6000W |
Working area | Sheet:1500mmx3000mm Tube:220mm diameter x 3 meters or 6 meters length |
Min line width | 0.1mm |
Positioning accuracy | 0.01mm |
Max cutting speed | 60m/min |
Max acceleration | 1.5G |
Transmission type | Precision dual gear rack transsmission |
Drving system | Servo motors |
Cutting thickness | Depending on laser power and material |
Assisting gas | Compressed air, oxygen and ni |
Cooling mode | Industrial circulation water chiller |
Visual positioning | Red dot |
Machine weight | Net 4500kg |
Working voltage | 3 phase 380V 50HZ/60HZ |
Model | SFC3015 |
Laser type | Fiber laser,1080nm |
Laser power | 1000W,1500W,2000W,3000W,4000W,6000W |
Working area | Sheet:1500mmx3000mm Tube:220mm diameter x 3 meters or 6 meters length |
Min line width | 0.1mm |
Positioning accuracy | 0.01mm |
Max cutting speed | 60m/min |
Max acceleration | 1.5G |
Transmission type | Precision dual gear rack transsmission |
Drving system | Servo motors |
Cutting thickness | Depending on laser power and material |
Assisting gas | Compressed air, oxygen and ni |
Cooling mode | Industrial circulation water chiller |
Visual positioning | Red dot |
Machine weight | Net 4500kg |
Working voltage | 3 phase 380V 50HZ/60HZ |
mainly consist of the laser part (including laser power supply, laser indicating system, optical system and refrigeration system), laser cutting head, CNC gantry table, iuycontrol system and cutting software, coaxial
auxiliary gas system, machine tools accessories, etc.
Our Factory
mainly consist of the laser part (including laser power supply, laser indicating system, optical system and refrigeration system), laser cutting head, CNC gantry table, iuycontrol system and cutting software, coaxial
auxiliary gas system, machine tools accessories, etc.
Our Factory
Applicable Industries
Fiber Laser Cutting Machine is widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED
Letters,Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks &Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts,Nameplates, etc
Applicable Industries
Fiber Laser Cutting Machine is widely used in manufacturing Billboard, Advertising, Signs, Signage, Metal Letters, LED
Letters,Kitchen Ware, Advertising Letters, Sheet Metal Processing, Metals Components and Parts, Ironware, Chassis, Racks &Cabinets Processing, Metal Crafts, Metal Art Ware, Elevator Panel Cutting, Hardware, Auto Parts, Glasses Frame, Electronic Parts,Nameplates, etc
